Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency

Hunan Jingshengda Ceramic Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency

  • 1
  • 2
  • 3

Brand Name : Kingda

Model Number : 0.1-50MM

Place of Origin : Hunan, China

MOQ : 1KG

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10 Ton / Month

Delivery Time : 3-7 Days

Packaging Details : 25KG/drum / 500-1000KG on pallet with shrink wrapped

Name : Zirconia Beads

Color : White

Material : Ceramic

Sample : Availabale

Specific Density : 6.02g/cm3

Moh's Hardness : 9

Applied Fields : Ink,Coating, Painting,Mineral,Magnetic...

Certificate : ISO9001:2008/RoHS

Weight : 25kg/Barrel

Glossiness : 0.2

Sphericity : 99%

Composition : 99.9% Zirconia

Contact Now

Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency



Product Description————————


1. Zirconia grinding beads is also called Zirconia grinding ball or Zirconia ceramic ball or Zirconium bead or ultrafine grinding media.

2. Zirconia material has advantages of high hardness, high strength, high tenacity, high wear resistance and good corrosion resistance which is widely applied in fields of ceramics, fire proofing material, machinery, electronic, photics, Aeronautics and astronautics, biology and chemicals and etc.

3. It owns gloss of pearl and smooth surface and is the best ball among all grinding media.



Application————————

1. Particularly suitable for vertical stirring mills, horizontal roller ball mills, vibrating mills and various high linear, speed pin- type sand mills.


2. For wet or dry ultrafine dispersion and grinding of pastes and powders without contamination.


3. Perfect grinding media with good flatness, smooth surface, bright,high density and high strength.


4. Wear and corrosion resistant product: coating, textile, pigment, dyeing.


5. High strength, high tenacity product: magnetic material, piezoelectric ceramics, dielectric ceramics.


6. Pollution prevention: medicine, food, cosmetics.


7. Ceramics: electronic ceramics, refractory ceramics, structural ceramics.


Properties and technique parameters————————

Performance Unit Parameter
Component Wt% 95±0.2%Zro2+5±0.2%Y2O3
Density g/cm3 6.00-6.05
Hardness GPa >11
Elasticity Modulus GPa 200
Thermal conductivity W/m.k 3
Coefficient of thermal Expansion 10*10-6/ºC(20-400) 9.6
Crush Strength KN ≥20(φ7mm)
Bending toughness MPam1/2 8
Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency
Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency
Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency



Features————————

high hardness; good wear resisitance, corrosion resistance; high mechanical strength; low wear loss

non-conducted, low thermal conduction, high thermal expansion rate

non-greased and self lubrication

light weight with low density, decrease in centrifugal load

   Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency                  Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency


Matching Machine——————

Available grinding jars in full sizes:

Zirconia ball mill jar, alumina ball mill jar, Agate ball mill jar, Tungsten ball mill, hard metal mill jar and etc.

Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency

Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency



Package & Shipping————————

Package Type:

25KG/drum / 500-1000KG on pallet with shrink wrapped

Port:

Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port.


Delivery time:
Within 3-7 working days from the date of payment receipt


Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency




Factory————————

   Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency    Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency    Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency    Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency






QC————————

Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency

Laser Particle Size Analyzer Vickers hardness tester Microscopic detection Testing Meter of Powder

Specific Area



FAQ————————


1.Q: What is the size in your products?

A: Our common size is 0.8-50mm. We can also produce according to your request.

2.Q: What is your terms of delivery?
A: FOB, CFR, CIF.

3.Q: Can you accept small quantity sample order before production?
A: Yes, we can offer sample for your testing first before production, but the customers have to pay the courier cost.

4.Q: What is your production time?
A: Generally, it will take 3-7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

5.Q: What is your terms of payment?
A: T/T 30% as deposit, 70% balance against the copy of original B/L. Or 100% L/C at sight. We'll show you the photos of the products and the copy of original B/L before you pay the balance.






Our Service————————

1. We can produce other grinding balls as your need.

2. We test all the goods before delivery.

3. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

4. If you have any questions, please contact with us without any hesitation, we will reply you in 2 hours.

Special Ceramic Zirconia Grinding Ball 3mm - 20mm Multi Size High Efficiency







ABOUT KINGDA————————

1. HUNAN KINGDA CERAMIC TECHNOLOGY CO.,LTD is a manufacturer of the Grinding Media Ball, Grinding Jars, Zirconium Dioxide, Zirconia structures, etc.

2. "Quality Is in the First Position forever", we have gained a high reputation and good recognition from a lot of domestic and overseas customers such as University of Oxford, Lough borough University, Peking University, Tsinghua University, etc.

3. We promise that we would make great efforts to provide high quality grinding products and best services for all customers in the coming years.

4. Nowadays, KINGDA CERAMIC MATERIALS has gained great reputation from our business partners. We will continue to contribute the best to realize mutual benefit and sustainability.

5. We appreciate your interest and support in the efforts and passion of KINGDA CERAMIC, the company of Human Technology.
