XQM-2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation

Name: XQM2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation
Brand: Kingda
Price: 1 USD

Wholesale XQM-2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation from china suppliers

Program Memory : 10 Grinding Recipes, Multi-Step

Discharge Size : 0.1μm Minimum

MOQ : 1 Set

Speed Range : 0-670 RPM

Payment Terms : T/T,L/C,Western Union,PayPal

Motor Power : 750W

Place of Origin : Hunan, China

Voltage : 220V/380V 50Hz/60Hz Selectable

Real-Time Monitoring : Speed, Time, Temperature, Running Status

Packaging Details : Export-grade wooden case with high-density foam padding, vacuum-packed main unit, shock-proof corner protection

Feed Size : ≤10mm

Model Number : XQM-2L-TS

Brand Name : Kingda

Supply Ability : 500 Sets per Month

Control System : 7-inch Touch Screen HMI + PLC

Capacity : 2L (500ml x 4 Jars)

Certification : CE, ISO 9001:2015

Delivery Time : 7-15 working days

Jar Material Options : Zirconia, Alumina, Agate, Stainless Steel, Tungsten Carbide

Price : USD 1,800-3,200 / Set

Contact Now

XQM-2L Touch Screen PLC Control Planetary Ball Mill

The XQM-2L represents the next generation of intelligent laboratory grinding with its advanced 7-inch touch screen HMI and PLC control system. This programmable planetary ball mill enables automated multi-step grinding recipes with real-time parameter monitoring, delivering precision and repeatability for demanding nano powder synthesis and sample preparation applications.

XQM-2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation

Intelligent Control System

7-Inch Touch Screen HMI

Intuitive full-color touch screen interface with graphical display of speed curves, temperature trends, and operational status for effortless parameter setting and monitoring.

PLC Programmable Control

Industrial-grade PLC controller supports up to 10 custom grinding recipes with multi-step programming: set different speeds, durations, and pause intervals for complex protocols.

Real-Time Parameter Monitoring

Continuous monitoring of rotation speed, grinding time, motor temperature, and running status with on-screen digital readouts and automatic fault alarm protection.

One-Touch Recipe Recall

Save and recall grinding programs instantly - ideal for laboratories running standardized SOPs across multiple operators and material batches.

Technical Specifications

Parameter	Specification
Model	XQM-2L-TS
Capacity	2L (500ml x 4 Jars)
Motor Power	750W
Speed Range	70-670 RPM
Control System	7-inch Touch Screen HMI + PLC
Program Memory	10 Grinding Recipes, Multi-Step
Voltage	220V/380V 50Hz/60Hz Selectable
Feed Size	≤10mm
Discharge Size	0.1μm Minimum
Transmission Ratio	1:2
Safety Features	Overload Protection, Emergency Stop, Door Interlock

Jar Material Compatibility

Zirconia (ZrO₂) Alumina (Al₂O₃) Agate Stainless Steel 304 Tungsten Carbide (WC) Nylon PTFE

Applications

Automated nano powder preparation with programmable multi-step grinding protocols
High-throughput sample preparation for XRD, XRF, and spectroscopic analysis
Mechanical alloying with precise control over milling energy and duration
Quality control laboratories requiring standardized, repeatable grinding SOPs
Battery material synthesis: cathode and anode powder processing
Pharmaceutical milling with documented process parameter traceability

Kingda delivers intelligent laboratory ball mill solutions trusted by research institutions and industrial labs worldwide. All our planetary ball mills feature CE certification and a one-year comprehensive warranty. Contact us now to discuss your grinding requirements and receive a tailored quotation.
